| Place of Origin: | China |
| Brand Name: | XD |
| Certification: | CE / ISO9001 |
| Model Number: | CNC-20 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard heat treated wooden case |
| Delivery Time: | 20 days |
| Payment Terms: | TT LC |
| Supply Ability: | 30 sets per month |
| Axis Number:: | 3 Axis | Servo Brand:: | Sanyo Denki |
|---|---|---|---|
| Optional Tools:: | Spring Length Gauge And Gas Cylinder | Computer:: | Yitu |
| Package:: | Wooden Case | Gross Weight:: | 950kgs |
| High Light: | spring winder machine,spring coiling equipment |
||
0.30-2.30mm 3-4 axis CNC20 universal extension spring machine
XD-CNC20 universal spring forming machine
Technical Parameter:
|
Model: |
XD-CNC20 |
|
Wire diameter: |
φ0.3～2.3 mm |
|
Axes: |
3 axes |
|
Maximum Outside Diameter: |
40mm |
|
Maximum Feeding Length: |
unlimited |
|
Maximum Manufacture Speed: |
100pcs/min |
|
Feed Speed |
200m/min |
|
Memory Number: |
1000PCS |
|
Wire Feed Servo Motor: |
2.7 KW |
|
Cam Servo Motor: |
2.7 KW |
|
Quin Servo Motor |
0.75 KW |
|
Power AC: |
220V 3P 50/60Hz |
|
Dimensions (L*D*H): |
1400X550X1600MM |
|
Wooden Case Dimensions |
1600x600x1700mm |
|
Machine Weight: |
900Kg |
|
Gross Weights |
950Kg |
Details:
1. CNC20 spring machine consists of cam axis, wire feeding axis, rotation core and rolling axis. The
mechanical part has eight sets of sliding blocks. The winch and cam rotation have three mechanical
part has eight sets of sliding blocks.The winch and cam rotation have three mechanical action types:
extruding,punching and molding.
2. The computerized cam rotation system can be set from 0.1- 359.9°, every two wire feeding wheels constitutes of one group, totally two groups.
3. The spring machine rotation core system is installed on the axis. The axis can rotate leftwards and
rightwards. The rolling axis is installed on the sliding house. The cam drives it rotate 360°, also can
control direction action or designated moves back and forth.
Our advantages:
1. The factory has about 15 years experience in this field, and the Founder Mr Bai has witnessed the Spring Industry development in China.
2. Main market: Europe (UK, Italy, Sweden, Romania, Poland, Estonia, Russia,Turkey)
Africa (South Africa, Egypt,Tunisia),
Asia (Korea, India, Malaysia, Vietnam, Iran, Thailand),
South America (Brazil, Argentina, Colombia, Cuba, Mexico)
3. We have established customer oriented quality management system, strengthen lasting innovation
and enhance after-sale services.
Applicated products:
